Video Screen

Figure 15.
When a video input is connected to the MTP input, the video can be previewed in the small
gray rectangle on the screen. This preview allows the video properties to be adjusted.
Use the
z
z
z
z

Touch Calibration Screen

After setting the Volume, Time, Network, and
second time to begin calibrating the touch area of the touchpanel.
Figure 16.
Press on the green box until the color reverts to gray with a white border and a second box
is highlighted. Repeat until all four boxes have been pressed and calibrated. At that point the
screen automatically returns to the
Pressing the
screen) saves all changes and exits the calibration screens.
Contrast: 064
Main
Down
Volume
Time
Brightness: 128
Network
Down
Video
Exit
Video Screen
or buttons to adjust:
Down Up
Contrast between 0 and 127 (default, 64)
Color between 0 and 127 (default, 64)
Brightness between 0 and 255 (default, 128)
Tint between 0 and 255 (default, 128)
+
Press and Hold
Highlighted Box
Until Color Changes
+
Touch Calibration Screen
button on any of the menu screens (not available on the touch calibration
Exit
Color: 064
Up Down Up
Tint: 128
Up Down Up
Video properties, press the
Main screen
(see page 18).
TLP 710CV • Initial Configuration and Calibration
Menu button a
+
+
21
