Audio input — see S-video or composite video MTP transmitters or
TLP VIM specifications
Number/signal type ........................ 1 stereo, balanced/unbalanced, line level, as part of a set of proprietary signals
Connector ...................................... 1 female RJ-45 (shared with video input)
Audio output
Speaker output .............................. 1 mono, 89 dB SPL, 0.1 watt, 0.1 m, half space
Frequency response ........................ 900 Hz to 6 kHz, ±5 dB
Playback format(s) .......................... WAV files: 8 bit PCM, mono, 8 kHz sampling
General
Power supply .................................. External
Power consumption
Device ..................................... 9.8 watts, 48 VDC (PoE)
Device and power supply ......... 13.5 watts, 120-240 VAC, 50-60 Hz
Power over Ethernet (PoE) input requirements
Temperature/humidity .................... Storage: -22 to +158 °F (-30 to +70 °C) / 10% to 90%, noncondensing
Cooling .......................................... Convection, no vents
Thermal dissipation
Device ..................................... 33.2 BTU/hr
Device and power supply ......... 45.9 BTU/hr
Mounting
Furniture mount ...................... With included hardware
Min./max. table thickness ............... 0.375" to 2.00" (0.95 cm to 5.08 cm)
Enclosure type ................................ Metal
Input: 100-240 VAC, 50-60 Hz
Output: PoE 802.3af compliant, 48 VDC, 0.35 A, 16.8 watts
Complies with PoE 802.3af, class 3
Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing
TLP 710CV • TLP 710CV • Specifications 39
