Specifications

Typical for 25 °C unless otherwise specified.
Specifications in italic text are guaranteed by design.

Power consumption

5 V PC auxiliary power / PCI bus power /
external regulated
External 7.5 V to 15 V unregulated supply

Output specification

Number
Contact configuration
Contact rating
Contact resistance
Operate time
Release time
Vibration
Shock
Dielectric isolation (between open contact)
Life expectancy
Power on state (no connection to DIO)

Environmental

Operating temperature range
Storage temperature range
Humidity

Mechanical

Card dimensions (without standoff)
Weight
Table 1. Power consumption specifications
All relays off
All relays on
All relays off
All relays on
Table 2. Output specifications
8
8 Form C (SPDT) NO, NC and Common available at screw terminals
6 A @ 120 VAC or 28 VDC resistive
100 milliohms max (initial value)
10 milliseconds max
5 milliseconds max
10 to 55 Hz (amplitude 1.5 mm)
10 G (11 milliseconds)
300 VAC, 50/60 Hz (1 minute)
10 million mechanical operations, min
Not energized. NC in contact to Common. (JP2 in NON-INVERT position)
Table 3. Environmental specifications
0 to 70 °C
-40 to 100 °C
0 to 95% non-condensing
Table 4. Mechanical specifications
229 mm (L) x 102 mm (W) x 20 mm (H)
9" (L) x 4" (W) x 0.8" (H)
0.6 lb.
4-1
15 mA typical, 20 mA max.
480 mA typical, 550 mA max.
20 mA typical, 25 mA max.
500 mA typical, 580 mA max.
Chapter 4
