VI.1 Menu Structure of Control Panel
1
2
VI.1.1 Function description of the keys
1. Direction keys
1) Operation via control panel:
▲▼ key: Scroll the menus for selection; reduce or increase the values on LCD.
◄► key: Move the cursor position over the number string on LCD.
2) When the printer is waiting:
▲▼ key: Move the media forward and backward;
◄► key: Move the p/h carriage to cleaning position for cleaning and move it back to original
SignJet JS310 Series User's Manuals
1.－ LCD
2.－ Function Keys
3.－ Direction Keys
Figure 6-1 Control Panel
position after cleaning.
- 22 -
VI

Basic Panel Operation

3
