III.2 Attention before Turning on the printer
1. In order to clean Print head easily, please prepare following items:
Flush solution
Non-woven fabric.
2. In order to inspect temperature and humidity of printing environment, please prepare relative
measurers. Requirement for environment:
Temperature: 20°C - 28°C
Humidity: 40% - 70% (non-condensing)
3. Power supply
Printer control power supply: AC200-240 V, 50/60Hz
Heater power supply: AC200-240 V, 50/60Hz
Drying fan power supply: AC200-240 V, 50/60Hz
Make sure the printer is well grounded.
It is better to use UPS stable-voltage power.
4. Requirement for computer
In order to avoid problems caused by computer, please choose high quality computer or brand.
Computer such as DELL or IBM, etc.
III.3 Port of Printer
USB 2.0
Installation:
Connect printer's USB and computer's USB directly.
Find driver for USB at UsbInstalFile/Try Setup under printer's driver.
III.4 Connect With Power
1. After all the parts installed, move printer to its working area and clean up the package.
2. Connect power cables, including power for printer and heater, printing data cable. Protective switch
only works for heater's power. Usually this switch should be at status of On (switch on above, far from
red point)
3. After finishing, turn on power. The Auto-ink-supply-system runs to pump ink from Main ink tanks to
Sub tanks.
4. Feed in media and printer enters waiting status.
5. Then go in test printing. Observe ink drop. If not good, clean Print head again.
Use the printer in environment 20°C-28°C. If temperature is low, wait for about 15-20 minutes after
turning ON the power supply (PRINTER power and HEATER power), and then confirm printing.
