Description of Ink Supply, Cleaning system and board

VII.1 Ink Supply and Cleaning System
1 2 3 4 5
1.－ Main ink tank C
2.－ Main ink tank M
3.－ Main ink tank Y
4.－ Main ink tank K
5.－ Flush solution tank
Figure 7-1 Main ink tanks
