XII.4 Maintenance for other parts
XII.4.1 Lubrication for Print head rail:
As normal regulation, user should add lubricating oil to Print head rail daily and never use compound
oils.
1. Add a few lubricating oil on a cotton fabric and move the Print head to original position. Brush the
Print head rail with the cotton fabric to create an average oil layer on the rail.
2. Power the printer and move the Print head unit left and right repeatedly;
3. Erase the oil smear on the both ends of the rail. Erase the oil drops on the rail again before
printer running.
XII.4.2 Feeding and take-up rollers:
Oil the gears of media feeding and take-up rollers monthly to avoid rust.
SignJet JS310 Series User's Manuals
- 63 -
