Media Transmission
Media Processing
Print head Height
Pre-heater & Dry System
Clamp
Print head Cleaning System
Safety System
Print Interface
Noise
Printer Size (including ink
tank) / Net Weight
Package Size
Input Voltage
Voltage for the Heating and
Drying System
Power(AC 220V applied)
Working Environment
The parameters above are subject to be changed.
Product Model
Print Technique
Resolution
Color Quality
Max Media Width
Max Printing Width
Min Printing Size
Output (m²/h)
(Designed values, not from
measurement)
SignJet JS310 Series User's Manuals
Roll media or sheet media (bigger than A4 or 210mm)
Auto feeding and take-up system, weight less than 70kg/roll
3mm-5mm above media adjustable
Auto heating after electrifying, the tiptop temperature is about 40°C
Manual adjustment media width
Auto positive pressure cleaning
Inside safety lock with auto shutting down function
USB2.0 interface (Windows 2000,XP etc)
Printing status≤70dB/waiting status≤40dB (ISO7779)
L 3820mm x H 1190mm x W 890mm / 330Kg
L 3920mm x H 1365mm x W960mm
AC 200-240V, 50HZ/60HZ
AC 200-240V, 50HZ/60HZ
2000W
Temperature: 20°C ~ 28°C
Humidity: 40% ~ 70%
JS310-18ES
Xaar 126 300dpi piezo head, 8 heads inside
200dpi,400dpi
Photo effect including 2 levels: Basic and High Quality
1860mm (thickness less than 1mm)
1800mm
A4 or 210mm (thickness less than 1mm)
Mode
180 x 200dpi 2pass
180 x 200dpi 4-2pass
180 x 200dpi 3pass
180 x 200dpi 6-3pass
180 x 200dpi 4pass
180 x 200dpi 8-4pass
180 x 200dpi 6pass
180 x 200dpi 8pass
360 x 400dpi
- 9 -
Output (m²/h)
27.5
14.5
19.2
10.5
14.5
7.5
10.5
7.5
14.5
