3.1.2 CHANGE INTERFACE

If you want to change the interface 3610, use one of the connected scanners to configure
the interface-related settings and it will pass the new settings to 3610, which will then
initialize and pass the settings to any other connected scanners.
1) Have the scanners read the "Set Connection" and "Serial Number" labels at the back
of 3610.
2) Within two minutes, connect 3610 to the USB port of PC. For USB Virtual COM, you
may need to install its driver first!
3) The scanners will connect to your computer via 3610.
4) Have one scanner read the "Enter Setup" label to enter the configuration mode.
5) Have the scanner read the desired interface label and configure its related settings –
"Activate USB HID & Select Keyboard Type"
"Activate USB Virtual COM"
6) Have the scanner read the "Update" label to exit the configuration mode.
7) After the scanner resumes connection with 3610, it will pass the interface-related
settings to 3610.
8) Upon receipt of the new settings, 3610 will initialize itself.
9) Updated with new settings, 3610 will pass the settings to other connected scanners.
Chapter 3 Setting up a WPAN Connection
Update
63
