1660 Barcode Scanner

2.1 BT HID

For BT HID, refer to
settings. Run any text editor on your computer, and the scanned data will be transmitted
to the computer.
HID Settings
Keyboard Type
Digits Layout
Capital Lock Type
Capital Lock State
Alphabets Transmission
Digits Transmission
Inter-Function Delay
Send "NR" to Host
2.1.1 ACTIVATE BT HID & SELECT KEYBOARD TYPE
When BT HID interface is activated, you will have to select a keyboard type to complete
this setting. By default, BT HID is activated on the 1660 scanner, and the keyboard type
is set to PCAT (US).
1) Read the label above to activate BT HID and select a keyboard type.
Note: If the scanner responds with one long beep (low tone) upon reading the label, it
means the current firmware of your scanner is earlier than version 1.21. Please
upgrade the firmware to version 1.21 or later!
2) Read the "Decimal
of desired keyboard type.
3) Read the "Validate" label on the same page to complete this setting.
42
User Guide
Chapter 3 – Setting up a WPAN Connection
Activate BT HID & Select Keyboard Type ...
Value" label on page 171. Refer to the table below for the number
Defaults
PCAT (US)
Normal
Normal
Off
Case-sensitive
Alphanumeric keypad
0 (ms)
Disable
Enter Setup
for related connection
