USING A GENERIC DONGLE

1) Refer to 3 .2.3 Connect to Dongle
4
request from your computer.
2) Read the following labels in sequence to configure the scanner to use BT SPP as
output interface.
3) Read the following labels in sequence for the scanner to enter the download mode.
The scanner will respond with beeps to indicate it is ready for downloading.
4) Run the download utility "ProgLoad.exe" on your computer.
1. For the communication settings, select "RS-232" and the correct COM port for BT
SPP interface, and ignore the baud rate setting.
2. For the file option, click [Browse] to select the target file for firmware update —
Kernel (K*.shx) or user program (STD*.shx).
3. Click [OK].
for the target scanner to accept the connection
Enter Setup
Activate BT SPP
(and read labels for PIN code ...)
Update
Enter Setup
Download
Appendix I
Update
Firmware Upgrade
159
