Removing the Hard Disk Drive Assembly

1. Turn the computer OFF and turn it over.
2. Remove the device in Bay One (see
3. Remove screw (Figure 2 -
1
4. Slide the HDD assembly forward, then lift it up out of the computer.
5. Remove screws - (Figure 2 -
2 5
.
a.
1
d.
"Removing the Bay One Device" on page 2 -
3a).
3e) from the assembly, and slide the hard disk
b.
8).
out of the case .
7 6
c.
e.
7
2
3
6
4
5
Removing the Hard Disk Drive Assembly 2 - 9
Disassembly
Figure 2 - 3
Hard Disk
Removal
Sequence
a. Remove the HDD
assembly screw.
b. Slide the HDD as-
sembly in the direc-
tion of the arrow.
c. Lift the HDD assem-
bly up.
d. Lift the HDD assem-
bly out of the com-
puter.
e. Remove the screws
and separate the
HDD from the case.
6. HDD case
7. HDD
• 5 Screws
