Removing The Bay One Device - EUROCOM D500P Service Manual

Disassembly

Removing the Bay One Device

Figure 2 - 2
Bay One Device
1. Turn the computer OFF.
Removal
2. Place the computer on a clean, stable surface and turn it over.
Sequence
3. Locate the release latch
4. Slide the release latch towards the unlock symbol and hold it in position.
a. Slide the release
5. With the release latch held in position, slide the device out slightly, then lift it up and out of the computer.
latch to the unlock
position and hold it
in position.
b. Partially slide the
device out partially.
c. Lift the device up
and out of the com-
puter.
2. Bay One Device
2 - 8 Removing the Bay One Device
(Figure 2 -
1
a.
1
c.
2a) for the Bay One device.
b.
2
