Installing the 802.11g Wireless LAN

Figure C - 3
Installation procedure for computers with Bluetooth modem and wireless LAN module.
802.11g Wireless
1. Turn the computer OFF.
LAN Installation
2. Remove the keyboard
Sequence
3. Gently pull latches
mainboard's module socket.
Pull the latches,
4. Connect the longer antenna cable
place the module on
the mainboard, and 5. Replace the shielding plate
connect the cable.
dure.
Note: If the computer
is using a standard
MDC modem mod-
ule, the shorter
(MAIN/ J1) and
longer (AUX/ J2) an-
tenna cables should
be connected to the
wireless LAN mod-
ule.
1. 802.11g Wireless
LAN module
C - 4
(see page 2 - 11), shielding plate
& in the direction of the arrows and carefully place the wireless LAN module
1 2
to the "J1" socket of the wireless LAN module .
4
(see page 2 - 12) and keyboard
1
(see page 2 - 12).
(see page 2 - 11) by reversing the disassembly proce-
1
2
in the
3
4
3
