Removing the CPU

1. Turn OFF the computer and turn it over.
2. Remove the screws - (Figure 2 -
1 3
a.
3. Remove the four screws from the heat sink in order
Caution
The heat sink, and
CPU area in general,
contains parts which
are subject to high
temperatures - Please
allow the area time to
cool before removing
these parts.
7a) from the CPU cover, and remove the CPU cover
b.
1
4
2
3
- as indicated (Figure 2 -
5 8
8 6
5 7
.
4
4
8).
Reassembly Screw
Order
When inserting a new
or replacement CPU,
make sure you insert
the screws in the
same order indicated
in Figure 2 - 8.
Disassembly
Figure 2 - 7
Processor
Removal
Sequence
a. Remove the three
screws and the CPU
cover.
b. Remove the CPU
cover.
Figure 2 - 8
Processor
Removal
Sequence
(cont'd)
Remove the four
screws from the
heat sink in the or-
der indicated.
4. CPU cover
• 7 Screws
Removing the CPU 2 - 13
