Disassembly

Removing the Bay Two Device

Figure 2 - 4
Bay Two Device
1. Turn OFF the computer.
Removal
2. Turn the computer over.
Sequence
3. Remove screw
4. Apply gentle but firm pressure at point
a. Remove the screw
from point 1 .
b. Apply pressure to
a.
point 2 to slide the
device out of the
bay.
3. Bay Two device
• 1 Screw
2 - 10 Removing the Bay Two Device
(Figure 2 - 4a).
1
(Figure 2 -
2
b.
1
c.
3
4b), and slide the device out of the computer.
2
