3. Separate the system fan cable
4. Lift the mainboard and DC/DC board
a.
3
b.
from the mainboard .
3 1
out of the bottom case
4
2
1
4
(Figure 2 - 19a).
2
1
4
Disassembly
Figure 2 - 19
Mainboard
Removal
Sequence
(cont'd)
a. Separate the sys-
tem fan cable.
b. Lift the mainboard
assembly out of the
bottom case.
1. Mainboard
2. Bottom case
3. System fan cable
4. DC/DC board
Removing the Mainboard 2 - 23
