Disassembly

Removing the DC/DC Board

Figure 2 - 20
DC/DC Board
1. Remove the battery
Removal
2 -
Sequence
module
2. Turn the mainboard over and remove screws
a. Remove screws 1
3. Carefully separate the DC/DC board
- 2 .
b. Separate the main-
a.
board from the DC/
DC board.
3. DC/DC board
4. Mainboard
2 - 24 Removing the DC/DC Board
(page 2 - 7), bay one device
10), keyboard (page 2 - 11) CPU
(page 2 - 20), HDD converter board
1
2
3
(page 2 - 8), hard disk assembly
(page 2 - 13), palm rest (page 2 -
(page 2 - 21) and mainboard
- (Figure 2 - 20a).
1 2
from the mainboard (Figure 2 -
3 4
b.
(page 2 - 9), bay two device
17), bottom case (page 2 - 18), Audio "DJ"
(page 2 - 22).
20b).
4
3
3
(page
