Operation Details
1 1
Remote controller
Remote controller
The remote controller transmits signals to the system.
FEEL
COOL
DRY
FAN
HEAT
5
SLEEP
2
TIMER
8
MODE
4
Note: Each mode and relevant function will be further specified in following pages.
Remote Controller presetting
The remote controller is not
manufacturer.
Each time after the remote controller replace batteries or is energized, the arrowhead will flashes on the front of
Heat or
Cool on LCD of the remote controller.
User can preset the remote controller type depending on the air conditioner type you have purchased as follows:
Press any button when the arrowhead flashes on the front of
Press any button when the arrowhead flashes on the front of
If you don t press any button within 10 seconds, the remote controller is preset as Heat Pump automatically.
Note :
If the air conditioner you purchased is a Cooling Only one, but you preset the remote controller as Heat Pump, it
doesn t bring any matter. But if the air conditioner you purchased is a Heat Pump one, and you preset the
remote controller as Cooling Only, then you CAN NOT preset the Heating operation with the remote controller.
TCL Air Conditioner Service Manual
SLEEP TIMER ON
TMIER OFF
AUTO
HIGH
MID
LOW
SWING
FAN
SWING
ON/OFF
er presetting presetting as Cooling Only Air Conditioner or Heat Pump by
ON/OFF button
1
Used to start and stop operation
when pressed.
TIMER button
2
Used to select TIMER operation.
UP button (TOO COOL button)
3
3
Used to increase the set room temperature
and time.
7
DOWN button (TOO WARM button)
4
Used to decrease the set room temperature
6
and time.
1
SLEEP button
5
Used to set or cancel sleep mode operation.
VANE control button
6
Used to adjust airflow direction.
7
FAN SPEED control button
Used to select the indoor fan motor speed:
Auto, High, Mid and Low.
8
MODE button
Used to select the type of operation mode: Feel,
Cooling, Dry, Fan and Heating(Only for Heat Pump).
Cool
Heat , Heat Pump is set.
16
, Cooling Only is set.
