Refrigerating Cycle System
Heat Pump
INDOOR UNIT
Indoor coil
thermistor
Indoor
heat
exchanger
Distributor
Room temperature
thermistor
Cooling Only
INDOOR UNIT
Indoor
Indoor coil
heat
thermistor
exchanger
Room temperature
thermistor
TCL Air Conditioner Service Manual
Refrigerant pipe
(Option)
(with heat insulator)
Flared connection
Flared connection
Refrigerant pipe
(Option)
(with heat insulator)
Refrigerant pipe
(Optional)
(with heat insulator)
Stop valve
(with service port)
Flared
connection
Stop valve
Refrigerant pipe
(Option)
(with heat insulator)
Reversing valve
(4- way valve)
Accumulator
Compressor
Capillary tube
Check
valve
Capillary tube
Compressor
Capillary tube
9
OUTDOOR UNIT
Outdoor
heat
exchanger
Defrost
thermistor
Refrigerant flow in cooling or Defrosting
Refrigerant flow in heating
OUTDOOR UNIT
Outdoor
heat
exchanger
Strainer
Refrigerant flow in cooling
Hide quick links:
Advertisement
Table of Contents
Troubleshooting
Need help?
Do you have a question about the TAC-07CS and is the answer not in the manual?
Questions and answers
Cual es la conexión de la entrada de corriente de split tcl
The power input connection for the TCL TAC-07CS split air conditioner is as follows:
- For the indoor unit: Connect terminals 1 (WHITE), 2 (BLUE), and 3 (BROWN) to the corresponding terminals on the outdoor unit.
- The power supply connects to terminals L (BROWN) and N (BLUE) on the indoor unit.
- A GREEN/YELLOW wire is used for grounding.
- A 25A circuit breaker or time delay fuse should be installed between the main power source and the unit if a power plug is not used.
This answer is automatically generated
