3.2 Room fan does not operate at all.
Motor bearing inserted
state
Fan(Blower) fixed state
Fan(Blower) contact state
TCL Air Conditioner Service Manual
Connector contact check
Motor-related parts check
Motor detail check
Error code check
Operation mode check
PCB ass'y check
Motor driving circuit
Relay output
14
Motor output connector
Motor capacitor
Coil resistance (TP)
Motor capacitor
Motor insulation resistance
Communication effor
Blower lock sensing
In dehumidifying, heating,
or artificial intelligence
operation, room fan may
be off.
