2. Four elements of air conditioning

1) Temperature
2) Humidity
3) The degree of purity : Remove dusts in the air, and keep smoke from exceeding the allowable degree of
4) Air flow
• Standard for feeling comfortable
Classification
Temperature
Relative humidity
Air flow

3. Principle of refrigerating cycle

3.1 Principle of refrigerating : It is as follows.
1) Sprinkling with water in summer causes to cool surroundings.
• Because water absorbs the heat of surroundings with evaporating.
2) Gasifying a liquid (R-22) which is easier to evaporate than water makes cooler.
• Because water evaporates at 100°C under 1 atmosphere but freon gas (R-22) does a very low temperature of
-40°C
3) It is an Airconditioner that the principle is used for.
TCL Air Conditioner Service Manual
: The dry-bulb temperature by cooling or heating room air.
: A comfortable humidity condition of room air is generally kept by the relative humidity of
air, and the room air is controlled into a given relative humidity condition.
concentration.
: To disperse properly the air regulated in temperature, humidity and the degree of purity
into indoor, make an appropriate air flow and keep uniformly the temperature/humidity
condition of room unit.
Summer
21 ~ 28°C
30 ~ 60%
0.2m/s or less
Winter
20 ~24°C
30 ~ 60%
0.2m/s or less
