3.5 Left/right louver does not operate at all.
At the moment the room fan is stopped, louver auto
swing is stopped, and if room fan is started, auto swing is
re-operated.
- Especially, it occurs while dehumidifying or heating.
TCL Air Conditioner Service Manual
Louver/link/cam assembly
Motor shaft assembly check
If a constant torque is felt when rotating louver by hands,
the assembled condition is normal.
(Disconnection/short
circuit/malconnection)
Blower operating condition
Step motor driving circuit
Synchronous motor driving circuit
check
Connector check
check
PCB ass'y check
17
