JAVIER
April 4, 2025
Cual es la conexión de la entrada de corriente de split tcl
1 comments:
Mr. Anderson
April 4, 2025
The power input connection for the TCL TAC-07CS split air conditioner is as follows:
- For the indoor unit: Connect terminals 1 (WHITE), 2 (BLUE), and 3 (BROWN) to the corresponding terminals on the outdoor unit. - The power supply connects to terminals L (BROWN) and N (BLUE) on the indoor unit. - A GREEN/YELLOW wire is used for grounding. - A 25A circuit breaker or time delay fuse should be installed between the main power source and the unit if a power plug is not used.
Need help?
Do you have a question about the TAC-07CS and is the answer not in the manual?
Questions and answers
Cual es la conexión de la entrada de corriente de split tcl
The power input connection for the TCL TAC-07CS split air conditioner is as follows:
- For the indoor unit: Connect terminals 1 (WHITE), 2 (BLUE), and 3 (BROWN) to the corresponding terminals on the outdoor unit.
- The power supply connects to terminals L (BROWN) and N (BLUE) on the indoor unit.
- A GREEN/YELLOW wire is used for grounding.
- A 25A circuit breaker or time delay fuse should be installed between the main power source and the unit if a power plug is not used.
This answer is automatically generated
