Leakage / Drainage - 1/5
Factor
Troubles &
Causes
1. Non-leveled indoor
Slanted
drainage
leaks
Indoors need to be leveled.
(For a better drain the install-plate may be
tilted 2~3° to drain-pan's drain side)
TCL Air Conditioner Service Manual
1. Indoors leveling
2. Drain hose connecting.
Water leaks caused by the inclined indoor unit and the drain hose's bad connecting.
Defect Details
Horizon
Install-plate
Weight
2. Mal-linked drain hose
Drain pan
Guidelines
Confirm the water draining is good or not by
poring water into the drain pan.
Connecting parts of drain pan and hose should
be well fixed with bond for waterproofing.
24
Evaporator
Connect hoses with drain pan
Case-5
