3.6 Connecting the cable between indoor
unit and outdoor unit
3.6.1 Connect the cable to the Indoor unit.
• Connect the cable to the indoor unit by connecting
the wires to the terminals on the control board indi-
vidually according to the outdoor unit connection.
(Ensure that the color of the wires of the outdoor unit
and the terminal No. are the same as those of the
indoor unit.)
• 7K~18K cooling model
Terminal on the indoor unit
Terminal on the outdoor unit
• 7K~18K heat pump model
Terminal on the indoor unit
Terminal on the outdoor unit
• 24K cooling model
Terminal on the indoor unit
Terminal on the outdoor unit
CAUTION
~18K Model
If a power plug is not to be used, provide a circuit breaker
between power source and the unit as shown below.
Main power source
Air
Conditioner
TCL Air Conditioner Service Manual
1
N
BROWN BLUE GREEN/YELLOW
GREEN/YELLOW
BROWN BLUE
1
N
1
N
2
3
YELLOW
BROWN
BLUE
GREEN/YELLOW
RED
RED
YELLOW
BROWN
BLUE GREEN/YELLOW
1
N
2
3
1
L
N
WHITE
BLUE
BROWN
GREEN/YELLOW
Power supply
WHITE BLUE
BROWN
L
N
1
N
L
Terminal on the outdoor unit
Circuit Breaker
Use a circuit
breaker or time
delay fuse.
CAUTION
The power cord connected to the indoor unit should be
complied with the following specifications
(Type H05VV-F(Indoor), H07RN-F(Outdoor) approved
by HAR or SAA).
The power connecting cable connected to the indoor
and outdoor unit should be complied with the following
specifications
(Type H07RN-F approved by HAR or SAA).
The connecting cable connected to the indoor and out-
door unit should be complied with the following specifi-
cations
(Type H07RN-F approved by HAR or SAA).
. 24K heat pump model
Terminal on the indoor unit
Power supply
.
L
24K~ Model
If a power plug is not to be used, provide a circuit breaker
between power source and the unit as shown below.
Main power source
Air
Conditioner
11
NORMAL
CROSS-SECTIONAL
AREA 2.5mm 2
(18K: 1.5mm 2 , 7K~14K: 1.0mm 2 )
NORMAL
CROSS-SECTIONAL
AREA 2.5mm 2
(18K: 1.5mm 2 , 7K~14K: 1.0mm 2 )
NORMAL
CROSS-SECTIONAL
AREA 0.75mm 2
1
2
3
L
BROWN BLUE
WHITE
RED
YELLOW
YELLOW
WHITE RED
BROWN
2
3
1
N
L
Circuit Breaker
Use a 25A circuit
breaker or time
delay fuse.
N
GREEN/YELLOW
BLUE
GREEN/YELLOW
N
