2. Tools required
2.1 Tools
Screw driver
Assembly,
Indoor installation
disassmbly
Core drill
Monkey spanner
(diameter 70mm)
(300mm): 2EA
Wall through
Indoor/Outdoor
pipe connection
Clamp meter
2.2 Accessory
Connnection cable
Indoor-Outdoor
Outdoor protection
wire connnection
in a unusedseason
Refrigerant pipe
(for high/low pressure)
Refrigerant circuit
Chaging of wall-
connection to
Indoor/Outdoor.
Remark: Some of the above parts are provided by the installer and not included in the standard air-conditioner.
TCL Air Conditioner Service Manual
Hand drill
Ruler, knife
Ruler: Length &
distance
measurement.
plate fixing
Knife: Tape cutting
Torque wrench
Indoor/outdoor
pipe connection
Winter cover
Anti-vibration
rubber
Vibration absorption
like winter
of outdoor
Putty
Vinyl tape
Wire & pipe
through hole
finishing
Gas leak detector
& soup water
Leak inspection
Hook meter
(for current measurement)
Current, voltage,
resistance
measurement
Level
Drive torch
Band
Wire & pipe
finishing
Remocon fixture
Remocon hanger
3
Thermometer
Hex. wrench
(Large side: 4mm, 5mm)
Temperature
measurement at
Service valve
Indoor suction
operating
inlet/discharge outlet.
Insulation
Flare tool set
resistance meter
Insulation resistance
Pipe cutting,
measurement
Burr removal
(Electric shock prevention)
Thermometer
Mega tester
Adhesive
Drain hose
Finishing
Drainage
Fixture clamping
Remocon
screw
Remocon fixture
fixing
