TCL
WALL MOUNTED SPLIT-TYPE AIR CONDITIONERS
SERVICE MANUAL
No.TE051220
Models
TAC-09CHSA/GI
TAC-12CHSA/GI
CONTENTS
···································2
·····················3
·······························4
············· 11
····························12
·············13
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for TCL TAC-09CHSA/GI
Summary of Contents for TCL TAC-09CHSA/GI
-
Page 1: Table Of Contents
WALL MOUNTED SPLIT-TYPE AIR CONDITIONERS SERVICE MANUAL No.TE051220 Models TAC-09CHSA/GI TAC-12CHSA/GI CONTENTS 1. IMPORTANT NOTICE ···································2 2. TECHNICAL SPECIFICATION ·····················3 3. OPERATION DETAILS ·······························4 4. WIRING DIAGRAM ············· 11 5. EXPLOSION VIEW ····························12 6. PARTS LIST ·············13... -
Page 2: Important Notice
TCL Air Conditioner Service Manual IMPORTANT NOTICE This service manual is intended for use by individuals possessing adequate backgrounds of electrical, electronic and mechanical experience. Any attempt to repair the appliance may result in personal injury and property damage. The manufacturer or seller cannot be responsible for the interpretation of this information, nor can it assume any liability in connection with its use. -
Page 3: Technical Specification
TCL Air Conditioner Service Manual Technical Specifications Model No. TAC-09CHSA/GI TAC-12CHSA/GI Type heating pump heating pump Control type remote remote Rated cooling capacity Btu/h 9,000(3,800~10,500) 12,000(5,200~13,500) Rated heating capacity Btu/h 10,250(4,200~13,000) 13,800(5,500~16,500) Moisture removal Liters/h High dB(A) Med. dB(A) Indoor noise level at cooling... -
Page 4: Operation Details
TCL Air Conditioner Service Manual Operation Details Remote controller Remote controller The remote controller transmits signals to the system. ON/OFF button Used to start and stop operation when pressed. TIMER button SLEEP TIMER ON TMIER OFF FEEL AUTO HIGH COOL Used to select TIMER operation. - Page 5 TCL Air Conditioner Service Manual Electronic Controller Safety Protection (1) Time Delay for Safety protection 3 minutes delay for compressor ---The compressor is ceased for 3minutes before restarting to balance the pressure in the refrigeration cycle in order to protect the compressor.
- Page 6 TCL Air Conditioner Service Manual (1) Compressor frequency control According to difference room temperature and set temperature(δt = RT-ST), running frequency of compressor is controlled by electronic controller. When room temperature is much higher than set temperature, compressor will start at a high frequency, and as room temperature goes down, compressor running frequency will go down.
- Page 7 TCL Air Conditioner Service Manual T e m p e r a t u r e u p s e t t i n g 37℃ l o w f a n 34℃ 33℃ b r e e z e 30℃...
- Page 8 TCL Air Conditioner Service Manual c o m p r e s s o r O F F 4 - w a y v a lv e O F F o u t d o o r f a n m o t o r...
- Page 9 TCL Air Conditioner Service Manual some reason, when power supply come back again, the AUTO-RESTART function will set synchronously and automatically to work. So the air conditioner would work at the same mode before. Auto-restart Pre-setting (optional): If Auto-restart function is needed, follow the steps below to activate this function: 1) Pulling the air-con's plug out of socket.
- Page 10 TCL Air Conditioner Service Manual Protection display code list: Protection type LED CODE DIGITAL LED CODE higher or lower voltage RUN-winking,TIMER-1 time/8s Over current RUN- winking,TIMER-2 times /8s Discharge temperature RUN- winking,TIMER-4 times /8s Over cooling in cooling mode RUN-light,TIMER-5 times /8s...
-
Page 11: Wiring Diagram
TCL Air Conditioner Service Manual Wiring diagram Model: TAC-09CHSA/GI, TAC-12CHSA/GI Indoor unit: Outdoor Unit:... -
Page 12: Explosion View
TCL Air Conditioner Service Manual EXPLOSION VIEW Indoor unit Model: TAC-09CHSA/GI, TAC-12CHSA/GI... -
Page 13: Parts List
TCL Air Conditioner Service Manual PART LIST Indoor unit Model: TAC-09CHSA/GI Part No. Part Name Q’ty Remark 1080030008 Installation plate 1210320107 Base 1070020016 indoor fan 1070100010 Bearing Mount 1110050067 Evaporator 1070320103 Water Drainage Assembly 1070320105 Vertical Vane Assembly 1070320121 Face frame... - Page 14 TCL Air Conditioner Service Manual PART LIST Indoor unit Model: TAC-12CHSA/GI Part No. Part Name Q’ty Remark 1080030008 Installation plate 1210320107 Base 1070020016 Cross fan 1070100010 Bearing Mount 1110050068 Evaporator 1070320103 Water Drainage Assembly 1070320105 Vertical Vane Assembly 1070320121 Face frame...
-
Page 15: Outdoor Unit
TCL Air Conditioner Service Manual EXPLOSION VIEW Outdoor unit Model: TAC-09CHSA/GI, TAC-12CHSA/GI... - Page 16 TCL Air Conditioner Service Manual PART LIST Outdoor unit Model: TAC-09CHSA/GI Part No. Part Name Q’ty Remark 1080050026 Grille 1190070021 Top cover 1110060083 Condenser 1080050004 Outdoor motor supporter 1170040058 Outdoor motor 1070030016 Propeller fan 1080050001 Left grille supporter 1080050007 Left grille...
-
Page 17: Part List
TCL Air Conditioner Service Manual PART LIST Outdoor unit Model: TAC-09CHSA/GI Part No. Part Name Q’ty Remark 1190070020 Base carton Not shown in explosion view 1190700302 Cabinet carton 1190070022 Base foaming 1190070021 Cover foaming... - Page 18 TCL Air Conditioner Service Manual PART LIST Outdoor unit Model: TAC-12CHSA/GI Part No. Part Name Q’ty Remark 1080050026 Grille 1080050011 Top cover 1110050069 Condenser 1080050004 Outdoor motor supporter 1170040058 Outdoor motor 1070030016 Propeller fan 1080050001 Left grille supporter 1080050007 Left grille...
- Page 19 TCL Air Conditioner Service Manual PART LIST Outdoor unit Model: TAC-12CHSA/GI Part No. Part Name Q’ty Remark 1190070020 Base carton Not shown in explosion view 1190700302 Cabinet carton 1190070022 Base foaming 1190070021 Cover foaming...
