MAX. REFRIGERANT PIPING LENGTH
Models
07K
09K
12K
18K
24K
MAX. HEIGHT DIFFERENCE
ADDITIONAL REFRIGERANT CHARGE(R-22 : g)
Models
07K
09K
12K
18 K
Models
24 K
TCL Air Conditioner Service Manual
Refrigerant piping
Max. length : m
A
10
15
Outdoor unit precharged
(up to 7m)
see <<Specification>>
see <<Specification>>
see <<Specification>>
Outdoor unit precharged
(up to 7m)
see <<Specification>>
Piping size O.D : mm
Gas
Liquid
9.52
6.35
12.7
15.88
9.52
Refrigerant piping length (one way)
7m
0
Refrigerant piping length (one way)
7m
0
10
Length of connecting pipe : m
Outdoor unit
Indoor unit
0.40
10m
15m
60
160
Calculation : Xg=20g/m
10m
15m
90
240
Calculation : Xg=30g/m
0
(A-7)m
(A-7)m
