Figure 4-17 shows the 1U riser cage.
PCIe riser
Figure 4-17 1U single slot PCIe riser cage

4.12.3 Network adapters

Table 4-25 lists other supported network adapters in the standard full-height
half-length PCIe slot.
Table 4-25 Network adapters
Part number Feature code
40 Gb Ethernet
00D9550 A3PN
10 Gb Ethernet
94Y5180 A4Z6
49Y7910 A18Y
00D8540 A4XH
49Y7960 A2EC
00D9690 A3PM
42C1800 5751
47C9952 A47H
47C9960 A47J
PCIe 3.0 x16 slot (full height,
half-length adapters)
Description
Mellanox ConnectX-3 FDR VPI IB/E Adapter for IBM System x
Broadcom NetXtreme Dual Port 10GbE SFP+ Adapter for IBM System x
Broadcom NetXtreme II Dual Port 10GBaseT Adapter for IBM System x
Emulex Dual Port 10GbE SFP+ VFA IIIr for IBM System x
Intel X520 Dual Port 10GbE SFP+ Adapter for IBM System x
Mellanox ConnectX-3 10 GbE Adapter for IBM System x
QLogic 10Gb CNA for IBM System x
Solarflare SFN5162F 2x10GbE SFP+ Performant Adapter for IBM
System x
Solarflare SFN6122F 2x10GbE SFP+ Onload Adapter for IBM System x
Chapter 4. IBM NeXtScale nx360 M4 compute node
