4.13 Integrated virtualization

The server supports VMware vSphere (ESXi), which is installed on a USB
memory key. The key is installed in a USB socket inside the server. Table 4-28
lists the virtualization options.
Table 4-28 Virtualization options
Part Feature
number code
41Y8298 A2G0
41Y8382 A4WZ
41Y8385 A584
Customized VMware vSphere images can be downloaded from this website:
http://ibm.com/systems/x/os/vmware/
Figure 4-18 shows the USB port inside the nx360 M4 where the IBM USB
Memory for VMWare ESXi is connected.
Figure 4-18 Location of the internal USB port for the virtualization key option
102
IBM NeXtScale System Planning and Implementation Guide
Description
IBM Blank USB Memory Key for VMware ESXi Downloads
IBM USB Memory Key for VMWare ESXi 5.1 Update 1
IBM USB Memory Key for VMware ESXi 5.5
Maximum
supported
1
1
1
