5.1.2 PDUs

There are several power distribution units that can be used with IBM NeXtScale
System. Listed in Table 5-2 are 1U rack units, which have 12 C13 outlets and are
supplied with 200 - 240 V 60 A, three-phase power or 380 - 415 V 32 A,
three-phase power.
0U PDUs: The IBM 0U PDU should not be used in the IBM 42U 1100mm
Enterprise V2 Dynamic Rack with the NeXtScale n1200 Enclosure because
there is inadequate clearance between the rear of the chassis and the PDU.
Table 5-2 PDUs for use with IBM NeXtScale System
Part number
Switched and Monitored PDU
46M4005
46M4004
Monitored PDU
39M2816
Basic PDU
39Y8941
The switched and monitored PDU (part number 46M4005) includes an attached
line cord with IEC 609 3P+G plug. The other PDUs require a line cord, which is
listed in Table 5-3.
Table 5-3 Line cord part number
Part number
40K9611
For assistance with selecting appropriate PDUs to configure, see one of the
following guides:
For North America and Japan:
http://www.ibm.com/support/techdocs/atsmastr.nsf/WebIndex/WP101526
For the International guide:
http://www.ibm.com/support/techdocs/atsmastr.nsf/WebIndex/WP101615
Description
IBM 1U 12 C13 Switched and Monitored 60 A 3-Phase PDU
IBM 1U 12 C13 Switched and Monitored PDU without line cord
IBM DPI C13 Enterprise PDU without line cord
IBM Enterprise C13 PDU
Description
32 A 380-415V IEC 309 3P+N+G (non-US) Line Cord
Chapter 5. Rack planning
121
