4.14 Local server management

The nx360 M4 provides local console access through the keyboard, video, and
mouse (KVM) connector on the front of the server. A console breakout cable is
used with this connector. The cable is shown in Figure 4-19.
Figure 4-19 Console breakout cable
One console breakout cable is shipped with the IBM NeXtScale n1200
Enclosure. Other cables can be ordered. The ordering part number is listed in
Table 4-29.
Table 4-29 Console breakout cable
Part
number
00Y8366
Same cable as Flex System: This is the same cable that is used with IBM
Flex System, but it has a different part number because of the included
materials.
Feature Description
code
A4AK Console breakout cable (KVM Dongle cable)
Chapter 4. IBM NeXtScale nx360 M4 compute node
Maximum
supported
1
