3.5 Fan modules

The IBM NeXtScale n1200 Enclosure supports 10, 80 mm fan modules. All fans
modules are at the rear of the chassis and are numbered as shown in Figure 3-7.
Figure 3-7 IBM NeXtScale n1200 Enclosure rear view with fan bay numbering
The fan modules provide cooling to the compute nodes. The fan modules have a
dual-rotor design for high efficiency and high reliability. Air flow is front-to-back.
Ordering information for the fan modules is shown in Table 3-11.
Table 3-11 Fan Modules
Part
number
00Y8570
42
IBM NeXtScale System Planning and Implementation Guide
10 9
Fan and Power
Controller
Default Information:
6
Static IP 192.168.0.100
User Name USERID
Password PASSW0RD
Zero
Event Log-Alternate Access
via USB Key
USB key
4 3
Feature Description
code
A41F n1200 Fan Module
8 7
Fan and Power Supply Bays
6 10 9 5 8 7
5
4 6 3 5
2 4 3 1 2 1
http://ibm.co/19pHxV8
2 1
Maximum Chassis
supported model
where used
10 A2x
