Note: The IMM2 Advanced upgrade requires the IMM2 Standard upgrade.
Table 4-30 Remote management options
Part number Feature
codes
90Y3900 A1MK
90Y3901 A1ML
The nx360 M4 provides a dedicated Ethernet port that allows connection to the
IMM2. It is a port to access the IMM2 separately from the onboard two-port 1 Gb
Ethernet controller. Alternatively, the first 1 Gb Ethernet port from the onboard
controller can be configured in Shared mode to allow access to the IMM2. With
Shared mode enabled, the dedicated IMM port is disabled.

4.16 External disk storage expansion

The nx360 M4 supports attachments to the external SAS storage expansion
enclosures using the ServeRAID M5120 SAS/SATA Controller. Table 4-31
provides the ordering part numbers.
Table 4-31 RAID controller and features for external locally attached storage
Part number Feature code
RAID controller
81Y4478 A1WX
Hardware upgrades
81Y4487 A1J4
81Y4559 A1WY
Features on Demand Upgrades*
a
81Y4546 A1X3
a
90Y4273 A2MC
a
90Y4318 A2MD
a. Use of any of the FoD upgrades for the M5120 requires one of the hardware upgrades - 81Y4487 or
81Y4559
Description
IBM Integrated Management Module Standard Upgrade
IBM Integrated Management Module Advanced Upgrade
(requires Standard Upgrade, 90Y3900)
Description
ServeRAID M5120 SAS/SATA Controller for IBM System x
ServeRAID M5100 Series 512MB Flash/RAID 5 Upgrade for IBM System x
ServeRAID M5100 Series 1GB Flash/RAID 5 Upgrade for IBM System x
ServeRAID M5100 Series RAID 6 Upgrade for IBM System x
ServeRAID M5100 Series SSD Performance Key for IBM System x
ServeRAID M5100 Series SSD Caching Enabler for IBM System x
Chapter 4. IBM NeXtScale nx360 M4 compute node
Maximum
supported
1
1
