Print Area

Print area
Supported width for borderless printing
*1: Printing may not be possible in some cases, depending on the type and size of paper.
*2: Varies depending on the operating system or application.
Options
Roll Holder Set
Print Area Print Area
A margin required by the printer is added with respect to the size of paper loaded in the printer. Except in border-
less printing, the actual printing area corresponds to the paper size minus the space for this margin.
•
Printable Area: The area that can be printed.
•
There is no margin (that is, a margin of 0 mm) during borderless printing on rolls.
Note
•
Recommended Print Area: We recommend printing within this area.
•
To print so that your original matches the print area exactly, use an oversized paper size that includes the required mar-
gin. (See "Printing on Oversized Paper.")
Top Edge
Sheets 3 mm (0.12 in)
Rolls 0/3 mm (0/0.12 in)
Sheets
• Printable Area
a margin of 3 mm (0.12 in) on top, 23 mm (0.91 in) on bottom, and 3 mm (0.12 in) on left and right sides is
648
required.
• Recommended Print Area
A margin of 20 mm (0.79 in) on top, 23 mm (0.91 in) on bottom, and 5 mm (0.20 in) on left and right sides is
required.
Normal size •
Sheets
3 mm (0.12 in) from the top, 23 mm (0.91 in) from the bottom, and 3mm (0.12
in) from the left and right sides
For information on the recommended print area, see "Print Area."
Borderless printing ( *2 ) Printable area (rolls)
0 mm from the top, 0 from the bottom, and 0 mm from the left and right sides
36-in. Roll (914.4mm), ISO A0/A1 Roll (841.0mm), JIS B1/B2 Roll (728.0mm),
24-in. Roll (609.6mm), ISO A1/A2 Roll (594.0mm), JIS B2/B3 Roll (515.0mm),
17-in. Roll (431.8mm), ISO A2/A3 Roll (420.0mm), 14-in. Roll (355.6mm),
300mm Roll (300.0mm), ISO A3/A4 Roll (297.0mm), JIS B4 Roll (257.0mm),
and 10-in. Roll (254.0mm)
→P.78
Margins of Printable Area
Bottom Edge Sides
23 mm (0.91 in) 3 mm (0.12 in)
0/3 mm (0/0.12 in) 0/3 mm (0/0.12 in)
RH2-33
Margins of Recommended Print Area
Top Edge Bottom Edge
20 mm (0.79 in) 23 mm (0.91 in)
20 mm (0.79 in) 5 mm (0.20 in)
iPF765
→P.648
Sides
5 mm (0.20 in)
5 mm (0.20 in)
