Automatic Banding Adjustment (Adj. Quality)

2
On the Tab Selection screen of the Control Panel, press ◀ or ▶ to
select the Settings/Adj. tab (
Note
3
Press the OK button.
The Set./Adj. Menu is displayed.
4
Press ▲ or ▼ to select Adjust Printer, and then press the OK button.
5
Press ▲ or ▼ to select Feed Priority, and then press the OK button.
6
Press ▲ or ▼ to select Adj. Priority, and then press the OK button.
7
Press ▲ or ▼ to select Automatic, Print Quality, or Print Length, and then press the OK button.
Automatic Banding Adjustment (Adj. Quality) Automatic Banding Adjustment (Adj. Quality)
If printed images are affected by banding in different colors across the sheet, execute Adj. Quality for automatic
adjustment of the paper feed amount.
There are two modes of automatic adjustment to correct banding: Auto(GenuinePpr) and Auto(OtherPaper). In
either mode, the printer prints and reads a test pattern for automatic adjustment of the feed amount.
• Auto(GenuinePpr)
Use this mode with paper identified in the Paper Reference Guide.
(See "Types of Paper.")
• Auto(OtherPaper)
Use this mode with paper not in the Paper Reference Guide, or if Auto(GenuinePpr) does not eliminate band-
ing.
(See "Types of Paper.")
•
Always check the Adj. Priority values before using Auto(GenuinePpr) or Auto(OtherPaper).
(See "Selecting a Feed Amount Adjustment Method (Feed Priority).")
Note
•
Adjustment is not possible with Auto(GenuinePpr) and Auto(OtherPaper) when using highly transparent media.
In this case, use Manual adjustment.
(See "Manual Banding Adjustment (Adj. Quality).")
•
If additional fine-tuning is necessary after Auto(GenuinePpr) and Auto(OtherPaper), execute Adj. Fine Feed.
(See "Fine-Tuning the Paper Feed Amount (Adj. Fine Feed).")
•
Use Adjust Length to ensure that lines in CAD drawings are printed at exactly the right length.
(See "Adjusting Line Length (Adjust Length).")
•
This may take some time, depending on the type of paper.
•
Use paper of the same type and size for adjustment as you will use for printing.
556 Paper to Prepare
Rolls An unused roll at least 10 inches wide
Sheets Auto(GenuinePpr) : One sheet of unused paper of at least A4/Letter size
Auto(OtherPaper) : Two sheets of unused paper of at least A4/Letter size (or one sheet when using A2 or larger)
).
•
If the Tab Selection screen is not displayed, press the Menu button.
→P.394
→P.394
→P.555
→P.557
→P.559
→P.559
