Configuring the Printer's AppleTalk Network Settings

2
In Show, choose Built-in Ethernet. Next, click Ap-
pleTalk, select Make AppleTalk Active, and click
Apply now.
3
Close the Network window and save the settings.
Configuring the Printer's AppleTalk Network Settings
Configuring the Printer's AppleTalk Network Settings
Follow the steps below to configure the AppleTalk network settings.
1
Start the web browser and enter the following URL in the Location (or Address) box to display the Remo-
teUI page.
http://printer IP address or name/
Example: http://xxx.xxx.xxx.xxx/
2
Select Administrator Mode and click Logon.
3
If a password has been set on the printer, enter the password.
4
Click Network in the Device Manager menu at left to display the Network page.
5
Click Edit in the upper-right corner of the AppleTalk group to display the Edit AppleTalk Protocol Set-
tings page.
6
Refer to the AppleTalk Settings Items table to complete the settings.
AppleTalk Settings Items
Item
Phase
Type
Name (*1)
Zone (*2)
504
*1: The object name you have specified in Name is displayed in Printer Setup Utility (or Print Center) in Mac OS X 10.2.8–
10.4. If you use multiple printers in the same zone, assign a unique name to each printer. By default, the network interface
name is Canon NB-18GB (xxxxxx). (Here, xxxxxx is the last six digits of the printer's MAC address.)
*2: If zones have been created on the network, enter the name of the printer's zone. If there are no zones, leave the asterisk *
entry (for the default zone) as it is. If you enter a network zone name that does not match created zones, the printer will not
be detected by Macintosh computers. Consult your network administrator for information on zone names.
Specify whether to use AppleTalk.
If you will use AppleTalk, choose Phase 2.
If you will not use AppleTalk, choose Disabled.
Specify the object name used by AppleTalk (in up to 31 single-byte or 15 double-byte charac-
ters).
However, do not use the following single-byte characters: @, *, :, and =.
Specify the printer zone name, up to 31 single-byte characters.
However, do not use the following single-byte characters: Also avoid using * (which represents
the default zone) in the middle of a string.
Details
iPF765
Default Setting
Disabled
Canon NB-18GB
(xxxxxx)
*
