REMOVAL & INSTALLATON OF REAR
DOOR GLASSES
REMOVAL
----Before removal of front door glasses, the
trim panel and waterproof film shall be
removed first following instructions.
----Pull out the inner and outer door waterproof
strips; begin the removal from the rib of the
internal side of the central door frame.
----Place the glass at the center of the door
frame. Loosen the fixing slot of the
window regulator support.
----When removing the glass, incline the upper
part of the glass towards outside direction
of the door.
Install in the reverse order of removal.
NOTE
Do not tighten the screw before until the
glass is installed in place properly.
REMOVAL & INSTALLATON OF REAR
QUARTER GLASS
REMOVAL
----Before removal of quarter glass, the trim
panel and waterproof film shall be removed
first following instructions.
----Take out the inner and outer pressed
moldings of the door, and remove them
from the rib position of the internal side of
the central door frame.
----Loosen the bolts between the central guide
rail and inner panel of the door, and
remove the central guide rail.
----Pull the quarter glass outwards and it
should be removed easily.
INSTALLATION
Install in the reverse order of removal.
S-37
