One way to separate the called party number is by Area Code, Exchange code and Subscriber Number.
This is difficult in an Open numbering system, in which the field size of area code, exchange code are not
standard but vary from two digits to four digits (e.g. the Area code for 'Mumbai' is of 2 digits, whereas that
of 'Vadodara' is 3 digits).
In the Closed numbering system, the Area Code, Exchange Code and the Subscriber number are of fixed
length. In such case, including '-' in the called party number is not difficult. Hence, '-' is put in the called
party number. The called party number is assumed to be of 10 digits. The first '-' is placed after four digits,
counting from the right. The second '-'is placed after seven digits, counting from the right. If the dialed
number is a local number of 7 digits then the second '-'is not placed. Also, the remaining three digits are
not placed, but filled with character 'space'.
In this case, even if the call is made to a geographical area where open numbering system is followed, '-' is
placed in the same way.
• Account Code: This is the Account Code (Refer Note4) using which the call was made.
• Remarks: This column indicates the details of the call; whether it was a DISA call, DOSA call, Auto
Redial Call, type of call maturity.
Fixed Characters are used to indicate the type of call, call details, etc. The notations for the Remarks
field are:
D DISA Call
A Auto Redial Call
C CPD
K 12KHz/16KHz
R Reversal
D Delay
I Connect
• Reset Serial Number to 001: The Serial number counter can be reset to 001 after 24 hours (from
00:00 HH:MM) or every 6 hours. By default, 'No Compulsory Reset' is selected, which means the serial
number counter will not be automatically reset.
• Starting Character - Increment Counter: Specify the starting character of the increment counter as
the serial number rolls over, in this field.
• Reset Increment Counter: The Increment Counter can be reset to 001 after 24 hours (from 00:00
HH:MM) or every 6 hours. By default, 'No Compulsory Reset' is selected, which means the serial
number counter will not be automatically reset.
• Prefix String Required: This flag is to be programmed if the prefix string 0ac1 is to be sent when
interfacing with OG-SMDR Posting Protocol.
• Property Code: Enter the property code required by the CAS.
• Currency Symbol (Enter Decimal Value): Enter currency symbol to be used.
