Matrix ETERNITY NE System Manual page 672

• When you assign a Macro to a DSS Key on a DKP or Extended IP Phone,
• you must select Macro as Function Type
• As Offset, you must select the Macro Index number (1-25) at which the number string is stored. In
this example, it would be Macro Index 1.
For detailed instructions on assigning a keyboard macro to a DSS key, see
"DKP Extensions"
Extensions"
• When creating a Macro for a special Key on an SLT,
• In the Number String field, enter the strings the system should consider as command when the special
key on the SLT is pressed.
• In the Access Codes field, enter the strings sent by the SLT on pressing the special function key.
For example, if the SLT sends the string '*53' to the ETERNITY NE when the function key for Alarms is
pressed, enter the string 163 (the feature access code for Voice-guided Alarms) in the Number String
field, and enter the string *53 in the corresponding Access code field.
The Access Code that you assign here in Macros must not conflict with any other Access Codes in the
Dial Phase. See
• Click Submit to save.
• Log out of Jives.
662
for instructions. Also see,
"Access Codes".
"Matrix Extended IP Phone Key Settings"
Matrix ETERNITY NE System Manual
"Phone Key Settings" under
under "SIP
