When you enable Rotation, each new outgoing call is routed through the subsequent trunk in the
30
group . This ensures equal distribution of outgoing call traffic on all trunks.
When Rotation is OFF, calls are routed through the first trunk in the group. If this trunk is busy, the call
is routed to the next trunk in the group.
Rotation has no relevance if only one member trunk is selected.
• Click OK. The multiple selection box closes.
All the trunks appear in the field Trunks allowed for '0' dialing, in the sequence you selected, separated
by commas. For example, BSNL (CO-1), BSNL (CO-3), Reliance (CO-4) and Pulver (SIP1).
To apply Least Cost Routing on the Trunks allowed for 0 dialing, select the desired LCR method from the
3.
combo box:
• Number Based: Choose this option if the service providers of the trunks you selected offer different
tariffs according to area or distance, or phone numbers dialed.
• Time Based: Choose this option if the service providers of the selected trunks offer a different tariff
according to the time of the day.
• Time + Number Based: Choose option if the service providers of the selected trunks offer different
tariffs according to the time of the day as well as area/distance/phone number.
• Service Provider Based: Choose this option if the same service providers of the selected trunks offer
different rates for calls made to numbers within their own network and for calls made to numbers of
another Service Provider's network.
• If you do not want to apply LCR, select OFF.
• Configure LCR method that you selected for the trunk group.
To configure Least Cost Routing method you selected, click the link LCR settings. A new window opens.
4.
• Go to the LCR method you selected for Trunks allowed for 0 dialing.
• Configure the LCR method. See Least Cost Routing under Advanced Settings for instructions.
• Click Submit.
• Close the window.
Select Trunks allowed for '5' dialing. The outgoing call will be routed through the selected trunks when
5.
the extension user dials TAC '5'. Follow the same steps as described above.
• Double-click the field. A multiple selection box opens.
• Select trunks, placing your cursor on the desired trunk, and clicking the Select>> button.
• Change the sequence of the trunks you selected, if required, using the Up and Down arrow buttons on
the right display box. Delete trunks from the ones you have selected, if required.
• Enable Rotation, if you have selected more than one trunk. Default: Disabled.
• Click OK.
All the trunks appear in the field Trunks allowed for '5' dialing, in the sequence you selected, separated
by commas.
• Choose a Least Cost Routing method, if you want to apply it on the trunks. Default: OFF.
• Configure the Least Cost Routing method you selected by clicking LCR Settings link.
30. The first call through the first trunk, the second through the second, the third through the third trunk, and so forth. Thus each new
call is routed through the trunk next to the one that routed the previous outgoing call.
