3. Power
Netbiter EasyConnect gateways are powered by the following:
9-24V DC
The power requirements of the various units are as follow:
•
Netbiter EasyConnect EC150 = 2 W
•
Netbiter EasyConnect EC220 = 2 W
•
Netbiter EasyConnect EC250 = 3 W
Note that Netbiter EasyConnect EC150 can alternatively be powered by 9-24V AC.
12-48V DC
The power requirements of the Netbiter EasyConnect EC350 vary depending on the types and numbers
of functions enabled at any one time. The unit will require an average of 4W, and a maximum of 6W.
3.1 Netbiter EasyConnect EC150 and EC250
On these models, connect 9-24V DC to pin V+ (or Vin+), and connect the ground wire to GND.
Netbiter EasyConnect
Doc.Rev. 2.10
Chapter 3
Doc.ID. HMSI-168-92
