5.4 Netbiter EasyConnect EC350

Note that while the unit is booting up, all the LED:s except the Power LED will show orange.

5.4.1 RS485 / RS232 LED

These two LED:s indicate the status of the serial ports, according to the following:
OFF: Port not in use
Steady red: Port not available
Contact HMS support.
Steady green: Port is configured for use.

5.4.2 Uplink/WAN LED

This LED indicates the status of the connection to Netbiter Argos/Internet.
Steady green: Connected to Netbiter Argos
One orange flash: No IP address
• For dynamic IP address - check for DHCP server on network.
• For fixed IP address - check the set IP address.
Two orange flashes: No connection to Argos/Internet
Check all network settings (gateway, DNS servers, netmasks, etc) and firewalls.
Netbiter EasyConnect
Doc.Rev. 2.10
LED Indicates
RS485 Status for RS-485 port
RS232 Status for RS-232 port
Uplink/WAN Connection status via WAN port
Modem Modem status, including signal strength
Gateway System status
Power Indicates when unit has power
Ethernet Link Network speed
(on RJ45 socket)
LED Indicators 31
