12.6 Specifications EC250 & EC350
Netbiter EasyConnect EC250
Order codes NB1003
Ethernet 10/100 Mbit/s
Mobile communication Quad band GPRS Class 12
850/900/1800/1900 MHz
Alarms Email, SMS
Relay output -
(max 24V AC/DC, 1A)
Digital inputs 2, isolated max 24V DC
Analog inputs -
Serial port #1 RS-232 up to 115.2 kbit/s
Serial port #2 RS-485 up to 115.2 kbit/s
Antenna connector SMA female
Protocols Modbus-RTU, ASCII, TCP
Modbus slaves 32
Baud rates 300-115200 baud
Wall mounting No
DIN rail mounting Yes
Dimensions (WxDxH) 90 x 70 x 58 mm
Operating temperature -30 to +65° C
Storage temperature -40 to +85° C
Housing class IP20
Power supply 9-24 VDC
Power consumption 3 W
Certifications CE
CU
FCC/IC (Pending)
PTCRB (Pending)
RoHS
Netbiter EasyConnect
Doc.Rev. 2.10
LU
S
Netbiter EasyConnect EC350
NB1005
10/100 Mbit/s
3G: 5-Band UMTS/HSPA+
(WCDMA/FDD)
(850/800, 900, 1900 and 2100 MHz)
GPRS: Quad-Band GPRS Class 12
(850/900/1800/1900 MHz)
Email, SMS
1
2, type dry contact
4 inputs, all supporting 0-10V or 0-20mA.
Support for PT100 on AI1 and AI3.
11-bit resolution. Raw value 0-2400.
RS-232 up to 115.2 kbit/s
RS-485 up to 115.2 kbit/s
SMA female
Modbus-RTU
32
1200-115200 baud
Yes
Yes (optional)
135 x 92 x 26 mm
-40 to +65° C
-45 to +85° C
IP20
12-48 VDC
4.5 W
CE
RoHS
Telec (Pending)
RCM (Pending)
LU (Pending)
CU S
FCC (Pending)
IC (Pending)
PTCRB (Pending)
ATEX/Haz Loc (Pending)
Dimensions & Specifications 66
