2.2 Netbiter EasyConnect EC150 & EC250
Wall Mounting
This option is not available for these models.
DIN-rail Mounting
Netbiter EasyConnect EC150 and Netbiter EasyConnect
EC250 are supplied ready for mounting on a DIN-rail.
To mount the unit on the DIN-rail:
1. Lower the unit onto the upper lip of the DIN-rail.
2. Press the unit towards the rail. It will snap into place
on the lower lip.
To remove the unit from the DIN-rail:
1. Insert a flat-head screwdriver into the slot on the
underside of the unit and pull/lever it down.
2. Pull the lower side of the unit free of the rail.
3. Lift the unit free of the rail.
