12.5 Specifications EC150 & EC220
Netbiter EasyConnect EC150
Order code NB1001
Ethernet 10/100 Mbit/s
GPRS -
Alarms Email, SMS
Relay output 1
(max 24V AC/DC, 1A)
Digital inputs 2
(isolated max 24V DC)
Analog inputs -
Analog output (0-10V) -
Serial port #1 RS-232 up to 115,2 kbit/s
Serial port #2 RS-232/RS-485 up to 115,2 kbit/s (isolated) RS-485 up to 115,2 kbit/s (isolated)
Antenna connector -
Protocols Modbus-RTU,
ASCII, TCP/IP
Modbus slaves 32
Baud rates 300-115200 baud
Wall mounting No
DIN rail mounting Yes
Dimensions (WxDxH) 90 x 70 x 58 mm
Operating temperature -40 to +65° C
Storage temperature -40 to +85° C
Housing class IP20
Power supply 9-24 V DC or AC
Power consumption 2 W
Certifications
CE, ROHS
Netbiter EasyConnect
Doc.Rev. 2.10
Dimensions & Specifications 65
Netbiter EasyConnect EC220
NB1000
-
Quad band GPRS Class 12
850/900/1800/1900 MHz
Email, SMS
1
2
2 (PT100, 0-10V or 0-20mA)
Resolution: 11.25 bit
(raw value 0-2400)
1
RS-232 up to 115,2 kbit/s
SMA female
Modbus-RTU
16
300-115200 baud
Yes
Yes (optional)
92 x 115 x 25 mm
-30 to +65° C
-40 to +85° C
IP20
9-24 V DC
2 W
CE, LU , FCC/IC, PTCRB
CU S
Doc.ID. HMSI-168-92
