Data

Problem
• Instrument or other system data is unavailable
at all Nav Stations.
• Instrument or other system data is missing from
some but not all Nav Stations.
Possible cause / solution
• Data not received at Master GPM.
• Data source (e.g ST70 instrument) is not
operating.
• Software mismatch between equipment may
prevent communication.
hs
• SeaTalk network problem
• Software mismatch between equipment may
prevent communication.
97
Possible solutions
• Check the data bus (e.g. SeaTalk
tion to the master GPM.
• Check the overall integrity of the data bus (e.g.
ng
SeaTalk ) wiring.
• If available refer to the reference guide for the data bus.
ng
(e.g. SeaTalk reference manual)
• Check the source of the missing data (e.g. ST70
instrument)
• Refer to the manufacturers handbook for the equipment in
question.
• Contact Raymarine technical support
• Check that all GPM400s are connected to the SeaTalk
switch.
• Check the status of the SeaTalk
Refer to troubleshooting Status LEDs on page
hs
• Check that SeaTalk cables are free from damage.
• Contact Raymarine technical support
Chapter 9: Troubleshooting
ng
) wiring and connec-
hs
hs
Switch.
98.
