4.7 SeaTalk network
hs
The SeaTalk network has 2 main purposes:
• Connection of digital devices.
• Networking of G-Series equipment.
hs
For a typical SeaTalk system see
hs
SeaTalk devices
The following digital devices communicate via the SeaTalk
network:
hs
• SeaTalk Switch
The hub of the network, this routes all network traffic.
• GPM400 processors
For sharing data over the network.
• GVM400 Video Module
For video distribution over the G-Series network. See
• Digital radar
• Digital sounder (e.g. DSM400)
For fishfinding applications. Refer to the separate instructions
supplied with the sounder.
• G-Series marine displays (G190, G170 etc.)
To allow control of display functions at the G-Series keyboard.
See page 38
• SR100 Sirius weather/audio receiver (North America only.)
To receive sirius satellite weather and audio services.
See also
hs
For a typical SeaTalk system see
For more details on the connections refer to the separate instruc-
tions supplied with the digital devices and the SeaTalk
page 19.
hs
page 43
page 19.
hs
switch.
hs
SeaTalk Network cables
All devices are wired individually back to the SeaTalk
using the following cables:
Cable
hs
SeaTalk network
1.5 m (4.9 ft) E55049
hs
SeaTalk network
cable
5 m (16.4 ft) E55050
hs
SeaTalk network
cable
10 m (32.8 ft) E55051
hs
SeaTalk network
cable
15 m (49.2 ft) A62135
hs
SeaTalk network
cable
20 m (65.6 ft) E55052
hs
SeaTalk network
cable
hs
SeaTalk patch
47
hs
switch
Notes
Network cables are used to connect
the GPM400 to the SeaTalk
switch.
Chapter 4: Cables and connections
