G-Series marine monitors
Resolutions and
VGA - 60,72, 75 and 85 Hz
refresh rates
SVGA - 56, 60, 72, 75 and 85 Hz
XGA - 60, 70, 75 and 85 Hz
SXGA - 60, 75 and 85 Hz
UXGA - 60, 65, 70, 75 and 85 Hz
All timings in accordance with VESA Monitor Timing
Standards
Approvals:
CE:
• 1999/5/EC, EN60945:2002
FCC:
• Part 80 (47CFR) and Part 2 (47CFR)
See also
•
For additional specifications, refer to the documentation sup-
plied with the individual equipment.
107
